【產通社，10月11日訊】羅姆株式會社（ROHM）官網消息，電路設計者選擇IC時，在組裝實際部件正式進行部件評估前，可通過在線設計工具“ROHM Electronic Labratory (ROHM E-Lab.) ”，在Web上簡單組裝電路，進行動作確認。另外，還可自由改變外置部件的數量和輸入信號，且能在動作確認后制作出電路的部件清單，從而大幅縮減部件選擇時間。今后將對“ROHM Electronic Labratory (ROHM E-Lab.) ”的產品陣容進行擴充，屆時請務必試用！

要使用新版ROHM Electronic Laboratory，請?jiān)L問https://www.rohm.com.cn/myrohm/www/cn/login.php注冊登陸。需要使用新版ROHM Electronic Laboratory的客戶，請抽空注冊并登陸MyROHM。（Lisa WU，365PR）

ROHM Electronic Laboratory的使用方法

ROHM Electronic Laboratory的功能：
. 可在Web上確認IC的動作。
. 可自由改變動作的條件及外置部件的數量。
. 進行動作確認后，可制作出部件清單。
. 可保存更新后的部件信息，之后可在相同的條件下對動作進行確認。
. 將依次擴充對應的產品系列及產品陣容。

ROHM Electronic Laboratory的對象機型

（1）內置有1chip FET的交換調整器
品名 名稱 ROHM E-Lab.
BD9001F Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9778F Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9778HFP Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9781HFP Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9006F Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9006HFP Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9007F Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9007HFP Flexible Step-down Switching Regulators with Built-in Power MOSFET
BD9106FVM Output 1.5A or Less High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9109FVM Output 1.5A or Less High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9120HFN Output 1.5A or Less High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9107FVM Output 1.5A or Less High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9130NV Output 2A or More High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9130EFJ Output 2A or More High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD9132MUV Output 2A or More High-efficiency Step-down Switching Regulators with Built-in Power MOSFET
BD95513MUV Output 2A or More High-efficiency Step-down Switching Regulators with Built-in Power MOSFET

（2）外置大電流FET的整流器式交換調整器
品名 名稱 ROHM E-Lab.
BD9018KV Step-down, High-efficiency Switching Regulators (Controller type)

（3）高性能PC用電源IC (交換整流器)
品名 名稱 ROHM E-Lab.
BD9533EKN Switching Regulators for DDR-SDRAM Cores
BD9535MUV Switching Regulators for DDR-SDRAM Cores
BD95513MUV Switching Regulators with MOSFET for DDR-SDRAM Cores

（4）H橋電機驅動器
品名 名稱 ROHM E-Lab.
BD6210F 7V Max. H-bridge Drivers
BD6210HFP 7V Max. H-bridge Drivers
BD6211F 7V Max. H-bridge Drivers
BD6211HFP 7V Max. H-bridge Drivers
BD6212FP 7V Max. H-bridge Drivers
BD6212HFP 7V Max. H-bridge Drivers
BD6220F 18V Max. H-bridge Drivers
BD6221F 18V Max. H-bridge Drivers
BD6222FP 18V Max. H-bridge Drivers
BD6222HFP 18V Max. H-bridge Drivers
BD6230F 36V Max. H-bridge Drivers
BD6231F 36V Max. H-bridge Drivers
BD6231HFP 36V Max. H-bridge Drivers
BD6232FP 36V Max. H-bridge Drivers
BD6232HFP 36V Max. H-bridge Drivers
